LED Glass panel light&down light

LED Glass panel light&down light

LED panel light adopts ultra-high brightness LED as the light source, which has the characteristics of flexible design, high illumination, less heat, long life, diverse ways of change, strong vibration resistance, strong control ability and low power consumption. It is suitable for indoor lighting in hotels, bars, western restaurants, cafes, home interior decoration and so on.

Features:

Additional information

Input voltage

85-265VAC 50/60Hz.

Beam angle

120° large distribution

Color temperature

3000K/4500K/6500K

Power Factor

>0.5

THD

<10

CRI

>80

SDCM

<10

Efficiency

>90%

Surge protection

According customer requirement

Working temperature

-15℃/+45℃

Warranty

1/2/3 Years

Certification

CB,SASO,CE,RoHS,UL,ETLCertified

Short description:

Material and finished

  • Housing: aluminum body
  • LGP:Glass、PS
  • Cover: GLASS, PP
  • Chips: LUMILEDS/EPISTAR/ SAMSUNG SMD2835 chips, 0.5W/chips. High lumens output.
  • Driver: Isolated driver or Non-isolated driver.
  • Screws: Stainless steel
  • Cables: 0.5²*2 input cable, High and low- temperature resistance, good insulation performance, it is ok to do cable diameter according to market requirement

Electrical & Optical

  • Input voltage: 85-265V 110-265V AC 50/60Hz.
  • Beam angle: 120° large distribution
  • Color temperature: 3000K/4500K/6500K
  • Power Factor: >0.5
  • THD: <10
  • CRI: >80
  • SDCM: <10
  • Efficiency: >90%
  • Surge protection: According customer requirement
  • Working temperature: -15℃/+45℃
  • Warranty: 1/2 Years

Applications

  • shopping mall lighting
  • Bank Lighting
  • Indoor lighting
  • Public places lighting

Additional Options

Standard accessories

installation manual

Optional accessories

connecting box

Sales repair spare parts list

·Power supply

·light source

·Drive board

·Spring



Power Item number Size of face ring
mm
Voltage
V
PF RA Iluminous
(Lm)
Life time(H) carton size PCS/CTN
6W OMB1-06 ø100 75 30 85-265V 0.5 80 240 20000 58.5 29 23 40
12W OMB1-12 ø160 120 30 85-265V 0.5 80 700 20000 64 35 22 30
18W OMB1-18 ø200 160 30 85-265V 0.5 80 1100 20000 64 43 26 20
24W OMB1-24 ø260 220 35 85-265V 0.5 80 1400 20000 64 28.5 32 10
6W OMB2-06 100*100 75*75 30 85-265V 0.5 80 240 20000 58.5 29 23 40
12W OMB2-12 160*160 120*120 30 85-265V 0.5 80 700 20000 64 35 22 30
18W OMB2-18 200*200 160*160 30 85-265V 0.5 80 1100 20000 64 43 26 20
24W OMB2-24 260*260 220*220 35 85-265V 0.5 80 1400 20000 64 28.5 32 10
