Led Batten Ceiling Light

Led Batten Ceiling Light

The LED batten ceiling light is a modern solution for commercial spaces. Designed to be mounted on the ceiling, this light features a slender shape that is ideal for illuminating long, narrow spaces such as hallways, aisles, and garages. Made from high-quality aluminum + durable PC shade, this light offers efficient, energy-saving performance and is affordable for illuminating your space. It’s also easy to install; screw the clips to the ceiling, allowing easy attachment of the fixture to the clips. This LED batten ceiling light produces a bright, even light perfect for illuminating your space.

Features:

Additional information

Type

Batten light

Model No

OJF-48

Light Source

Led

Color Temperature

3000K-6000K

CRI

>80

Power Factor

0.5

Input Voltage

85-265V

Warranty

1/2/3 Years

Certification

CB,SASO,CE,RoHS,UL,ETLCertified

SPECIFICATION

sizepowervoltage(V)LM/WLumen(LM)Led chips quantityCRI(Ra)power factor(PF)color temperatureLed chips specificationwithstand voltage(V)
1.2M48W85-265 105±%55040±%5216800.5

3000K

4000K

6000K

3.0-3.1V
0.5W/pcs
1500



Material and finished

High-quality aluminum profiles, oxidized (silver)

Cover: transparent pc material, UV resistant. High light transmission rate of more than 90%, strong sealing performance.

Chips: LUMILEDS/EPISTAR/ SAMSUNG SMD2835 chips, 0.5W/chips. High lumens output.

Driver: Isolated constant current led driver, safe solution. Strong surge protection.

  • Bracket: Metal, black powder-coated finished. 180° rotation.
  • Stand: stainless steel
  • Cables: 0.75²*3 input cable, High and low- temperature resistance, good insulation performance

Electrical & Optical

  • Input voltage: 85-265VAC 50/60Hz.
  • Beam angle: 180° large distribution
  • Color temperature: 3000K/4500K/6500K
  • Power Factor: >0.6
  • THD: <15%
  • CRI: >80
  • SDCM: <5
  • Efficiency: >88%
  • Working temperature: -15℃/+45℃
  • CB SASO CE RoHS Certified
  • Warranty: 2/3 Years

Applications

  • Hotel & Hospitality Lighting
  • Office, meeting room lighting
  • Home, bar lighting
  • Lighting for entertainment venues

IMAGES

VIDEOS

FAQs

Payment of our company will be T/T, L/C, etc

Energy saving by about 80% compared to traditional.

LED batten light is an electrical accessory that contains a tube light and provides artificial light and can be mounted on the ceiling or wall.

Yes, energy saving and environmental protection.

If you want install in Kitchen, it is ok.
